CONCEPT-4i

4 Channel DSP Amp
CONCEPT-4i
CONCEPT-4i
CONCEPT-4i
CONCEPT-4i

CONCEPT-4i

4 Channel DSP Amp

Flux Concept 4i is a DSP Amplifier with a minimalist design yet maximum power. It is the top choice for audiophiles seeking a processor with stable performance and low distortion. delivering exceptional sound clarity with efficient power usage.

As a DSP device, CONCEPT 4i is supported by software featuring a simple yet highly flexible UI, allowing you to fine-tune your sound with ease.
  • Plug n Play DSP Amplifier
  • 4 x 50 Watt Max @4ohm Output Power
  • OUTPUT 6 low-level RCA channels, 4 high-level channels
  • AKM high-performance DSP chip 269MHz/48KHz/24bit
  • Freq. Response : 20Hz ~ 20KHz
  • Professional Desktop PC tuning software with full function
  • 31 band per channel

SPECIFICATION

Power Output
4CH × 50W (Max) (4Ω, 14.4V, 1kHz, 1% THD)
High Input
4 Channel
Output DSP
6 low-level RCA channels, 4 high-level channels
Working Voltage
DC 9V ~ 17V
Signal Divider Filter Type
Butterworth, Linkwitz Riley, Bassel
Equalizer Output
31 band / channel
Size
160 x 127 x 42 mm

MANUAL & DATA SHEET
